  Features:
  1.Carbon steel body, compact, safe
  2.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,
  which enhance the wind energy utilization and annual output.
  3.Patented permanent magnet ac generator with special stator,effectively reduce torque,
  well match the wind wheel and generator, and ensure the performance of whole system.
  4.Tail adopts mechanical yaw technique, making it survive storm and run safely
  5.With epoxy zinc rich primer and polyurethane anti-corrosion treatment,
  be ultraviolet-proof, acid rain resistant, salt resistant
  6.Controller,inverter can be matched accroding to customers’ specific needs



Parameter




Model

NE-10kG

Rated power

10kw

Maximum power

13kw

Rated voltage

220/240/380v

Start-up wind speed

3m/s

Rated wind speed

10m/s

Survival wind speed

45m/s

Top net weight

400kg

Wheel diameter

8.2m

Number of blades

3

Blades material

 Reinforced glass fiber

Generator type

Three phase permanent magnet AC synchronous generator

Magnet material

NdFeB

Generator case

Carbon steel

Control system

Electromagnet/wind wheel yaw

Speed regulation

Tail furling

Working temperature

-40°C  -  80°C

Design life

20 y

Certificates

CE, ISO14001, ISO 9001,TUV
