1kW-1.5kW-2kW household wind turbine suitable for farms or rooftops, starting at low wind speeds, easy to install
● The overall components are lightweight, flexible, and easy to lift, install, and disassemble. ● Multi level safety protection such as electromagnetic brakes and automatic adjustment of windward angle with independent intellectual property rights of the company, ensuring safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data. ● Adopting a…
| Power: |
1kW-1.5kW-2kW |
|---|---|
| System Type: |
Horizontal Wind Turbine |
-
Start-up wind speed
2.5m/s
-
Rated wind speed(m/s)
11-12m/s
-
Survival wind speed(m/s)
45m/s
-
Number of blades
3
-
Blades material
Nylon fiber
-
Magnetmaterial
NdFeB
-
Generator case
Casting aluminum alloy
-
Control system
Electromagnet
-
Speed regulation
Automatically adjust windward direction
-
Working temperature
-40°C - 80°C
● The overall components are lightweight, flexible, and easy to lift, install, and disassemble.
● Multi level safety protection such as electromagnetic brakes and automatic adjustment of windward angle with independent intellectual property rights of the company, ensuring safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data.
● Adopting a direct drive permanent magnet generator with upwind direction, automatic adjustment of wind direction, and no gearbox transmission design, the whole machine has low starting wind speed, small size, light weight, beautiful appearance, and low operating vibration.
| Model | NE-1000M6 | NE-1500M8 | NE-2000M10 |
| Power(kw) | 1kw | 1.5kw | 2kw |
| Rated voltage(V) | 48v/96v/120v/192v/220v/240v/380v | ||
| Start up speed(m/s) | 2.5m/s | 2.5m/s | 2.5m/s |
| Rated wind speed(m/s) | 11-12m/s | 11-12m/s | 11-12m/s |
| Survival wind speed(m/s) | 45m/s | 45m/s | 45m/s |
| Number of blades | 3 | ||
| Blades material | Nylon fiber | ||
| generator | Three-phase AC permanent magnet synchronous generator | ||
| Magnetmaterial | NdFeB | ||
| Generator case | Casting aluminum alloy | ||
| Control system | Electromagnet | ||
| Speed regulation | Automatically adjust windward direction | ||
| Working temperature | -40°C – 80°C | ||
| Design life | 20 y | ||
Professional manufacturer of small and medium-sized wind turbines
Adopting a direct drive permanent magnet generator, with upwind direction and automatic adjustment of windward angle, without gearbox transmission design, the whole machine has low starting wind speed, small size, light weight, beautiful appearance, and low operating vibration.
Having multiple certifications such as CE and ISO14001, as well as multiple intellectual property patents
Multi level safety protection such as electromagnetic brakes and automatic adjustment of windward angle with independent intellectual property rights of the company, ensuring safe and stable operation of the wind turbine in extreme weather conditions based on real-time monitoring data.
Low starting torque of motor, reducing starting wind speed and improving wind energy utilization efficiency
Adopting humanized design, the overall components are lightweight, flexible, and easy to lift, install, and disassemble.
Suitable for applications such as small wind farms, smart grids, microgrid systems, etc.
